AIR BLASTER INSTALLATION
Air Blaster Installation
Efficient, reliable and high-performance air blaster installation solutions for industrial applications.
ABOUT AIR BLASTER INSTALLATION
Powerful Cleaning Solutions for Industrial Applications
Air Blaster is very effective and economical method of removing jamming in Bunkers, make Chutes, Kiln Inlet, Coolers, Chutes, Hoppers and Silos etc. and it ensures smooth and continuous flow of materials. It can be installed at any place and its operation is very simple. Even an unskilled worker can operate it with full satisfaction. It works on compressed air 5-7Kg/cm² which is delivered through pipe lines. Generally plant air is adequate. In case when plant air is not available at the site, small compressor or can be installed as per the requirement for operation of Air Blaster is not much. It is operated when jamming takes place. By installing this equipment's, hazardous manual poking with rod can be avoided. The cost of installing Air Blasters is quickly recovered through the increased efficiency and reduces down time from the creation of free material flow. EVEN A SINGLE PREVENTED ACCIDENT CAN PAY FOR A COMPLETE INSTALLATION.
Operating Sequence – Pre-Heater Riser Duct
Operating Sequence of Air Blasters should be maintained from TOP to BOTTOM in case of Pre-heater Riser Duct.
Operating Sequence – Hopper, Bunker, Chute etc.
Operating Sequence of Air Blasters should be maintained from BOTTOM to TOP in case of Hopper, Bunker, Chute, Cyclone etc.
APPLICATIONS
Where Air Blasters Are Used
Air Blasters installed for removing coating in Cyclone-Riser Duct Bend.
Air Blasters installed for removing coating in Grate Cooler.
Air Blasters installed for removing coating in Pre-Heater Inlet Chamber (Duct).
Heat recovery process in Co-generation from D.G. Sets.
PRODUCTS RANGE
Air Blaster Specifications
| MODEL | DISCHARGE | TANK CAP (LITERS) | FAD AT(7kg/cm2) (in liters) |
APPLICATION |
|---|---|---|---|---|
| AB-05-020 | 050mm | 20 | 140 | Chutes, Small Section |
| AB-10-050 | 100mm | 50 | 350 | Chutes, Feed Pipes |
| AB-10-070 | 100mm | 70 | 490 | Chutes, Feed Pipes, Cyclone |
| AB-10-100 | 100mm | 100 | 700 | Feed Pipe, Cyclone & Riser Duct |
| AB-10-150 | 100mm | 150 | 1050 | Cyclone, Riser Duct, Cooler, Hopper |
| AB-10-300 | 100mm | 300 | 2100 | Cooler, Hoppers, Bunkers, Silos |
| AB-15-150 | 150mm | 150 | 1050 | Cooler, Hoppers, Bunkers, Silos |
| AB-15-300 | 150mm | 300 | 2100 | Cooler, Hoppers, Bunkers, Silos |
